KSLJ-281-24-0611c-14cM6x11 cross, D15x14cross,A=24mm
Delme mesafesi (A): 24
Detaylar: haç
Uzunluk (L): 42
Diş: M6
| 24 | haç | 42 | M6
| - | - | - | |
KSLJ-281-24-0811c-18cM8x11 cross, D15.5x18 cross,A=24mm | - | - | - | - | - | - | - | |
KSLJ-281-24-0815c-18cM8x15 cross, D15.5x18 cross, A=24mm | - | - | - | - | - | - | - | |
KSLJ-281-24-0815c-18hM8x15 cross, D15.5x18 hex, A=24mm | - | - | - | - | - | - | - | |
KSLJ-281-24-0815c-22cdowel M8, A=24mm
Delme mesafesi (A): 24
Diş: M8
Dübel merkezi (x): 8
Çap (D): 15
Delme derinliği (h): 14 | 24 | - | - | M8
| 8 | 15 | 14 | |
KSLJ-281-30-0811c-18cM8x11 cross, D15.5x18 cross,A=30mm | - | - | - | - | - | - | - | |
KSLJ-281-30-0811c-22cM8x11 cross, D15.5x22 cross,A=30mm | - | - | - | - | - | - | - | |
KSLJ-281-30-0811i-18cM8x11 slot, D15.5x18 cross,A=30mm | - | - | - | - | - | - | - | |
KSLJ-281-30-0885c-22cM8x8.5 cross, D15.5x22cross,A=30mm | - | - | - | - | - | - | - | |
KSLJ-281-34-0608c-14cM6x8 cross,D15x14 cross,A=34mm | - | - | - | - | - | - | - | |
KSLJ-281-34-0611c-14cM6x11 cross, D15x14 cross,A=34mm
Delme mesafesi (A): 34
Diş: M6
Dübel merkezi (x): 8
Çap (D): 15
Delme derinliği (h): 14 | 34 | - | - | M6
| 8 | 15 | 14 | |
KSLJ-281-34-0808c-18cM8x8 cross,D15.5x18 cross,A=34mm | - | - | - | - | - | - | - | |
KSLJ-281-34-0815c-18cM8x15 cross,D15.5x18 cross,A=34mm | - | - | - | - | - | - | - | |
KSLJ-281-34-0815c-22cdowel M8, A=34mm
Delme mesafesi (A): 34
Diş: M8
Dübel merkezi (x): 8
Çap (D): 15
Delme derinliği (h): 14 | 34 | - | - | M8
| 8 | 15 | 14 | |
KSLJ-281-34-0815i-22cM8x15 slot,D15.5x22 cross, A=34mm | - | - | - | - | - | - | - | |
KSLJ-281-34-0815i-22hM8x15 slot,D15.5x22 hex, A=34mm | - | - | - | - | - | - | - | |
